Milton Roy mRoy B - MODEL Mroy B12 & M12 PLASTIC LIQUID END PARTS (FIGURE 24)

68Installation, Operations & Maintenance Manual
6.17 LIQUID END mRoy K (FIGURE 24)
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
280 Contour Plate - Oil Side 298-0014-006 Steel 1
285 Contour Plate - Process Side 298-0014-006 Steel 1
298-0014-016 316 SS 1
298-0014-028 Alloy 20 1
298-0014-030 Alloy C-22 1
290 Diaphragm - 3.390 Dia. 298-0015-075 PTFE 1
300 Head, Diaphragm 54186 316 SS 1
54286 Alloy 20 1
350 Screw Hex Head - 7/16-14 x 1-1/2 405-0019-149 Steel 4
355 Screw Hex Head - 7/16-14 x 2-1/4 405-0019-171 Steel 4
-
Base, Simplex
201-0395-000 1
Base, Duplex
201-0428-000 1
370
Screw, Hex Head - 5/16-18 x 1-1/2
Gr5
405-0017-149 Steel 3
390 Lock-Washer, Spring - 5/16 404-0040-028 Zinc Plated 3
400 Nut, Hex - 5/16-18NC 405-0065-013 18-8 SS 3
460 O-Ring, Discharge Check Valve Cap 408-0068-113 PTFE 1
510
Check valve, Discharge 54345 316 SS 1
54346 Alloy 20 1
54413 Alloy C-22 1
520 Nut Lock - Check Valve 209-0020-014 303 SS 1
530
Ring, Spiral Back Up
408-0073-141 PTFE 1
540 O-Ring, Check Valve Lock Nut - 2- 116, 408-0068-065 FKM (VITON) 1
600
Check valve, Suction 221-0896-216 316 SS 1
221-0896-228 Alloy 20 1
221-0896-030 Alloy C-22 1
6.18 MODEL mRoy B12 & M12 PLASTIC LIQUID END PARTS (FIGURE 24)
Conversion Kit (P/N: PARTSKIT307) includes the following parts:
- Parts Not Illustrated
Parts Continued Next Page
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
280 Contour Plate - Oil Side 298-0014-006 Steel 1
281 Pin, Orientation 211-0043-071 PVC 1
285 Contour Plate 298-0038-071 PVC 1
290 Diaphragm - 5.230 Dia. 298-0013-075 PTFE 1
330 Head, Diaphragm 221-0359-071-001 PVC 1
