Milton Roy mRoy B User Manual

51 Installation, Operations & Maintenance Manual
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
280 Contour Plate 298-0061-016 316 SS 1
290
Diaphragm 5” 298-0005-175 PTFE
1
330 Head 54092 PVC 1
340 Plate, Back-Up 54321 304 SS 1
350 Screw, Hex Head - 5/16-18 x 2 405-0017-163 18-8 SS 8
360 Fastprime Valve 48848 PVC 1
390 Lock-Washer, Spring - 5/16 404-0040-028 Zinc Plated 3
400 Nut, Hex - 5/16-18NC 405-0065-013 18-8 SS 3
435
Seal- Head to Check Valve (PVC & PVDF
Checks)
408-0143-075 PTFE
2
500
Nut, Coupling - Tubing Connection ONLY 407-0350-079
2
540
O-ring 4080068065 Viton
1
490
Check Valve Assembly, Suction -Tube End 20287 PVC
1
Parts Included
O-Ring - 3/8 x 3/32 225-0032-675 PTFE
2
Ball Stop 20289 PVC 2
Seat 20290 PVC 2
Ball, 3/8 Ad995 407-0015-111 Ceramic 2
Body, Cartridge 20288 PVC 1
490
Suction Assembly, NPT 20299 PVC 1
Suction Assembly, BSP 54379 PVC 1
Parts Included
O-Ring - 3/8 x 3/32 225-0032-675 PTFE 2
Ball Stop 20289 PVC 2
Seat 20290 PVC 2
Ball, 3/8 Ad995 407-0015-111 Ceramic 2
Body, Cartridge 20291 PVC 1
495 Discharge Assembly-Tube End 20292 PVC 1
6.9 MODEL mRoy A: E & F PLASTIC LIQUID END PARTS (FIGURE 19)
- Parts Not Illustrated
Parts Continued Next Page
600
Valve Body, Suction 221-0864-016 316 SS 1
221-0864-028 Alloy -20 1
221-0864-030 Alloy C-22 1
