6.11 ELECTRONIC CAPACITY CONTROL MOUNTING (FIGURE 23)
Complete Kits: 30268 7/16”, 3/8” & 5/8” plungers & 335-1401-040 for 1-1/16” plunger. Parts included
are below:
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
140
Plug, Adapter - RA & RP Pumps (1” NPT) 243-0045-020 Steel 1
Plug, Adapter - RT, RH, & RJ Pumps (1/2”
NPT)
243-0045-000 Steel
1
150 O-Ring, Parker - 2-011 408-0109-082 Polyurethane 3
160 Control Spool 268-0037-006 Steel 1
170 Sleeve, Threaded 243-0058-016 316SS 1
180
Screw, Socket Set - 6-32NC x 1/4 405-0039-035
1
190 Plate, % Capacity 253-0015-062 Aluminum 1
200 Ring, Calibration 253-0024-062 Aluminum 1
210 Knob, Capacity Adjust 255-0035-077 Acetal 1
213
Bearing, Control Spool ECC 237-0076-052
1
217 Washer, Thrust - 5/16 404-0147-031 Steel 1
220 E-Ring (1/4” for Control Knob) 404-0124-096 Steel 1
810
Coupling, Drive ECC 252-0138-077
1
820 Lock-Washer - #6 404-0104-071 Steel, Zinc Plated 2
830 Screw, Pan Head - 6-32NC x 3/8 405-0178-033 18.8SS 2
840
Bracket, Mounting, Mroy A ECC 204-0149-006
1
860 Nut, Serrated Flange - 1/4-20NC 405-0323-036 Steel, Zinc Plated 1
880 Screw, Socket Head - 5/16-18 x 5/8 405-0157-024 Steel / Nylon 1
900
Actuator (mRoy) per SPEC
1
910
Sha, Drive ECC Assembly: Includes Items
915 & 920.
268-0055-000
1
915
Pin, Dowel - 1/8” Assemble w/268- 0052-
077
401-0021-133
1
920 Pin, Spring - 0.187dia.x 5/8 401-0005-032 Steel 1
930 Lock-Washer, Spring - 3/8” 404-0041-022 18.8SS 4
935 Screw, Hex Head - 3/8-16 x 3/4 405-0018-096 Steel, Zinc Plated 4
950 Guard, Left Side ECC 249-0110-006 Steel 1
960 Guard, Right Side ECC 249-0109-006 Steel 1
970 Screw, Button Head - 10-32 x 5/16 405-0282-087 18.8SS 4
1440
Mroy ECC Instruction Manual 339-0083-000
1
