69 Installation, Operations & Maintenance Manual
6.19 mRoy B MOTOR MOUNTS (FIGURES 17 & 18)
Parts Common To All Motor Mounts
Worm and Shaft Assembly includes Stub Shaft (640), Worm (650), Spring Pin (660), Tapered Roller
Bearing (670), and Single Roll Bearing (680).
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
650
Worm, worm gear, and Shaft
Assembly
54703 38:1 48 spm @1725 RPM
1
54702 25:1 72 spm @1725 RPM
1
54701 19:1 96 spm @1725 RPM
1
54700 12.5:1 144 spm @1725 RPM
1
54699 9.5:1 148 spm @1425 RPM
1
670
Bearing, Tapered Rolle 409-0066-010
1
680
Bearing, ball 409-9994-000
1
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
- Head Assembly Kit, Diaphragm (Includes
330, 522, 523, 524 , 526,
and 527)
221-0393-100
340 Reinforcing Plate, Upper 204-0088-016 316SS 1
345 Reinforcing Plate, Lower 204-0089-016 316SS 1
350 Screw, Hex Head - 7/16- 14 x 2-1/2 405-0019-187 18-8S 4
355 Screw, Hex Head- 7/16-14 x 5 405-0019-297 18-8SS 6
- Base, Simplex 201-0395-000
1
-
Base, Duplex
201-0428-000
1
510
Check Valve Assembly, Discharge (In-
cludes 430, 511, 512, 513, 514,
515,516, and 541)
221-0464-007 PVC
1
221-0464-009 PVDF
1
517 Plate, Compression 204-0091-016 316SS 1
518 Plate, Compression 204-0090-016 316SS 1
519 Nut, Hex- 5/16-18NC 405-0065-013 18-8SS 4
521 Stud- 5/16-18UNC x 10 1/4 232-0014-216 316SS 2
522 Ball - 3/8" Dia. 407-0015-111 Ceramic AD995 1
523 Diaphragm- 0.703 Dia. 298-0062-075 PTFE 1
524 Bushing- 1/2 NPT 237-0049-171 PVC 1
526 Plug, Purge 243-0047-171 PVC 1
527 Connector, (Tubing 1/4 x 1/4) 402-04 79-028 PVC 1
540 0-Ring,-3-916, 1.171 x0.116,
Check Valve
408-9998-151 FKM (VITON)
2
600 Check Valve Assembly, Suction 221-0360-007 PVC / Ceramic Ball 1
221-0360-009 PVDF
1
MODEL mRoy B12 & M12 PLASTIC LIQUID END PARTS (FIGURE 24)
