72Installation, Operations & Maintenance Manual
6.21 SIMPLEX LEAK DETECTOR PARTS- GAUGE & NEMA SWITCH (FIGURE 25)
- Parts Not Illustrated
Parts Continued Next Page
915
Pin, Dowel - 1/8 x 1-3/8 401-0021-143 Steel
1
920
Pin, Spring, 0.187 x 13/16 CRS 401-0005-062
1
930
Lock-Washer , Spring - 3/8 404-0041-022 18-8 ss
4
935
Screw, Hex Head - 3/8-16 x 3/4 405-0018-096 Zinc Plated
4
950
Guard, Side 249-0108-006
2
970
Screw, Button Head - 10-32 x 5/16 405-0282-087 18-8 ss
4
1442
Mroy ECC Instruction Manual 339-0002-000
1
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
Double Quantities For Duplex Pumps
ELECTRONIC CAPACITY CONTROL MOUNTING (FIGURE 23)
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
290 Diaphragm, 5.230 Dia. 298-0013-075 PTFE 2
Diaphragm, 3.390 Dia., K Plunger 298-0015-075 PTFE 2
300 Ring Assembly, Intermediate 219-0089-116 316 ss 1
Ring Assembly , Intermediate K Plunger 179-1260-116 316 ss 1
