60 Installation, Operations & Maintenance Manual
- Parts Not Illustrated
Parts Continued Next Page
DRAWING
NUMBER
LOCATION DESCRIPTION PART NUMBER MATERIAL/SPM Quanty
289 O-Ring 2-041 Viton 4080109385 VITON 1
290 Diaphragm XT- GYLON .030 THK 40741 GYLON 2
300 Intermediate Ring -A- XT11 21029 316 SS 2
301 Intermediate Ring-B- XT11 21031 316 SS 2
304 Spring Pin 1/16 X 3/8 18-8 S/S 4010001041 3
320 Contour 316SS 22134 316 SS 1
350 Hex Hd Screw 3/8-16 X 3-1/4 GR8 54461 STEEL 8
360
Base, Simplex Mroy A 201-0441-006 1
Base, Duplex Mroy A 201-0434-006 1
370 HEX HD SCR 5/16-18X1-1/4 GR8 4050017139 STEEL 2
380 BRACKET 2040199006 316 SS 1
390 SPRING LOCK WASHER 5/16 Z PL 4040040028 SS 2
400 5/16-18 HEX NUT SS C0-0065 SS 2
1148 TUBE CONN 1/8 TUBEX 1/8NPT 316 40061 316SS 1
1148 TUBE CONN 1/8 TUBEX 1/8NPT 316 40061 316SS 1
1150 CHECK VALVE 1/8TUBE 1/3PSI 316 40065 316SS 1
1160 PRESS GAGE 0-5000 PSI DUAL FLG 40405 1
1170 RED ADAPTER 1/4F X1/8M NPT 316 40067 316SS 1
1191 TEE 1/8NPT FEMALE 316SS 40062 316SS 1
1210 BLEED VALVE 1/8 NPT 316SS 40063 316SS 1
1220 PAN HD SCR #4-40X1/2 ZNCR 4050263050 3
1230 SPRING LOCK WASHER #4 18-8SS 4040095023 18-8 SS 3
1240 4-40 NUT SS C0-0051 SS 3
1270 Hex HD Screw 1/4-20X3/4 18-8SS 4050016095 SS 2
1280 Washer, 1/4” Split Lock, 18-8 L12216 18-8SS 2
6.15 SIMPLEX LEAK DETECTION PARTS, FIGURE 22 (DOUBLE QUANTITIES FOR DUPLEX
PUMPS) (THIS PARTS LIST IS APPLICABLE ONLY TO mRoy C, D PUMPS, ALSO “V”
CHECK VALVE OPTION)
