66Installation, Operations & Maintenance Manual
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
180
Screw, Socket Set, Cup Pt. - 6-32NC x
1/4
405-0039-035 1
190
Decal, Capacity
253-0026-062 1
200 Ring, Calibration 253-0025-062 Aluminum 1
210 Knob, Control 255-0020-062 Aluminum 1
220
E Ring Clip, External
404-9983-151 1
230
Plunger, Control
212-0048-039 1
240
Arm, Linkage
214-0014-006 1
250
Screw, Socket Head - 8-32NC x 1/2
405-0245-031 Steel 2
1061 Screw, Socket Set - 7/16-14 x 3/8 405-0133-024 Steel 2
1062
Screw, Socket Head - 8-32 x 1-5/8
(Locking Micrometer)
40224 Steel 1
1063
Nut, Hex - 8-32 NC 18-8SS (Locking
Micrometer)
405-0061-017 Steel 1
1330
Cap, Reservoir Simplex
432-0457-0060N 1
Cap, Reservoir Duplex
281-0269-000 1
1340
O-Ring, Parker - 2-216, Simplex,
Reservoir Cap
408-0095-071 BUNA 1
O-Ring Parker - 2-216, Duplex,
Reservoir Cap
408-0095-075 VITON 1
1350 Screw Plug - 7/8-14 405-2001-021 Plastic 1
-
Plate, Data
253-0186-000 1
- Parts Not Illustrated
Parts Continued Next Page
6.16 LIQUID END mRoy L, R (FIGURE 24)
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
280 Contour Plate - Oil Side 298-0012-006 Steel 1
285
Contour Plate - Process Side 298-0016-016 316 SS 1
298-0016-028 Alloy 20 1
298-0016-030 Alloy C-22 1
290 Diaphragm - 5.230 Dia. 298-0013-075 PTFE 1
350
Screw, Hex Head - 7/16-14 x 1-1/2
Gr5
405-0019-149 Steel 8
355 Screw, Hex Head - 7/16-14 x 2-3/4 405-0019-191 Steel 2
BASIC PARTS LIST FOR DRIVE MODELS mRoy B (FIGURES 17 & 18)
