74Installation, Operations & Maintenance Manual
6.23 DOUBLE DIAPHRAGM PARTS- WITH CONDUCTIVITY PROBE FOR PLASTIC LIQUID END
(mRoy M & B) (FIGURE 26)
290 Diaphragm 5.230 Dia. 298-0013-075 PTFE 2
324 Intermediate Chamber 20539 316 ss 1
326
Probe, Alarm Conductivity 301-0307-000
1
Plug, Pipe- 3/8", Used without Alarm
Probe
402-0011-033 316SS
1
327 Plug, Pipe- 1/8" Threaded 402-0011-013 316 ss 1
328
Oil, Vegetable 40104 105-115 ml
(3.6-3.9 oz)
355
Screw, Hex Head- 7/16-14 X 3 1/2 40448 18-8 ss 4
Screw, Hex Head- 7/16-14 X 6 40447 18-8 ss 6
DRAWING
LOCATION
NUMBER
DESCRIPTION PART NUMBER MATERIAL/SPM QUANTITY
- Parts Not Illustrated
Parts Continued Next Page
