Disassemble the Assemblies
Repair and Disassembly
6 - 48
046-006272-00
A7™ Ser
vice Manual
6.2.7
Remov
e the M
odule Rack F
an
1.
Remove the m
odule rack as
sembly.
2.
Unplug the cable pl
ug for modu
le rack fan.
3.
Unscrew the
four scr
ews to remo
ve the module
rack bracket assembly.
FIGURE 6-105
4.
Unscrew the
two screws to
remove
the fan and bracket.
FIGURE 6-106
5.
Unscrew the f
our screws to remov
e the module rack fan.
FIGURE 6-107
405
407
