Disassemble the Breathing System Repair and Disassembly
6 - 74 046-006272-00 A7™ Service Manual
6.3.4 Remove the Absorbent Canister
1. Hold and turn the rotary handle clockwise for 45 degrees.
FIGURE 6-158
2. Pull out the absorbent canister horizontally.
FIGURE 6-159
WARNING: Sodalime is a caustic substance and is a strong irritant to eyes, skin and
respiratory system. Affected areas should be flushed with water. If
irritation continues after flushing with water, seek medical assistance
immediately.
