Disassemble the Breathing System
Repair and Disassembly
6 - 84
046-006272-00
A7™ Ser
vice Manual
6.3.13
Remov
e the Air
wa
y Pressure Gauge
Lift the air
way pr
essure gauge straight u
p to rem
ove it.
FIGURE 6-177
6.3.14
Remov
e
the Bag Arm
1.
Unscrew the
locking nut counterclockwise an
d lift straight up to r
emove bag arm.
FIGURE 6-178
2.
Remove the bag arm from the bag arm mount.
FIGURE 6-179
