6-12 BeneVision N17/BeneVision N15/BeneVision N12 Patient Monitor Service Manual
6.5.4 Removing the Wi-Fi Module
1. Press the clips at two sides of the Wi-Fi socket, and take out the Wi-Fi module from the socket.
2. Remove the adhesive tape fixing the antenna, and tear off the Wi-Fi sticker antenna.
3. Pull out the Wi-Fi antenna plug from the board; unscrew the three M2X4 screws, and separate the
Wi-Fi module from the Wi-Fi support board.
Wi-Fi module
Wi-Fi support board
