Mitsubishi LANCER 2012 User Manual

7-52
Vehicle care and maintenance
7
*- Fusible link
● Some fuses may not be installed on your vehicle, depend-
ing on the vehicle model or specifications.
● The table above shows the main equipment corresponding
to each fuse.
There are no 7.5 A, 25 A or 30 A spare fuses. If a fuse of one of
these capacities blows, replace it temporarily by borrowing one
of the fuses indicated below.
7.5 A: 10 A spare fuse
25 A: 20 A spare fuse
30 A: 30 A audio amplifier fuse
Replace the borrowed fuse with a fuse that has the correct
capacity as soon as possible.
Identification of fuse
23 Fuel pump
Except for
vehicles with
turbocharger
15 A
Vehicles with
turbocharger
20 A
24 Starter 30 A*
25
Valve lift con-
trol
Except for
vehicles with
turbocharger
40 A
——
Vehicles with
turbocharger
—
26 Anti-lock braking system 40 A*
27 Anti-lock braking system 30 A*
28
Air conditioning condenser fan
motor
30 A*
29 Radiator fan motor 40 A*
30 IOD IOD 30 A
31 Audio amplifier 30 A
32 Diesel 30 A
33 — Spare fuse 10 A
34 — Spare fuse 15 A
35 — Spare fuse 20 A
No. Symbol Electrical system Capacity
Capacity Color
7.5 A Brown
10 A Red
15 A Blue
20 A Yellow
25 A Natural (White)
30 A Green (fuse type)/Pink (fusible link type)
40 A Green
