6-22

For emergencies

Towing

N00837000745

If your vehicle needs to be towed

If towing is necessary, we recommend you to have it done by a

commercial tow truck service.

When towing is required, transport the vehicle using a tow

truck.

Incorrect towing equipment could damage your vehicle.

OTE

● Your vehicle cannot tow any other vehicle.

There may be local regulations concerning towing in your area.

Obey the regulations of the area where you are driving your

vehicle.

CAUTION

● Do not attempt to be towed by another vehicle with

a rope.

Type A

Type B

Type C

Type D

Type E

Towing with front wheels off the ground.

Do not tow all-wheel drive vehicles with this style.

Towing manual transaxle vehicles with rear wheels

off the ground.

Do not tow continuously variable transmission

(CVT) vehicles or all-wheel drive vehicles with this

style.

BK0102103US.book 22 ページ２００９年１０月２６日　月曜日　午後１時３８分
