7-44

Vehicle care and maintenance

Drive belt (for generator, power steering pump,

air conditioning compressor)

N00941900267

Check the tension of the drive belt. Make certain that the indi-

cator (A) is between the specified lines as shown in the illustra-

tion.

Check the drive belt for cuts and cracks, and replace it if it is

damaged. When replacing the belt, make sure that there is no

interference between the belt and other engine components.

After replacing, recheck the tension to make sure the indicator

(A) is between the specified lines.

Except for vehicles with turbocharger

WARNING

● Do not check or touch the drive belt with the engine

running, or serious injury or death may result.

Vehicles with turbocharger
