Motorola APX 5500 User Manual

Follow the procedure to lock and unlock a site using the radio menu.
Procedure:
1 or to Site.
2 Press the Menu Select button directly below Site.
3 Perform one of the following actions.
• To lock the site, press the Menu Select button directly below Lock. The display shows Site
locked.
• To unlock the site, press the Menu Select button directly below Unlk. The display shows
Site unlocked.
The radio saves the new site lock state and returns to the Home screen.
2.17.7
Site Display and Search Button
The Site Display and Site Search button allows you to view the name of the current site or force your
radio to change to a new one.
2.17.7.1
Viewing the Current Site
Procedure:
Perform one of the following actions:
• Press the preprogrammed Site Search button.
•
or to RSSI and press the Menu Select button directly below RSSI.
The display shows momentarily the name of the current site and its corresponding received RSSI.
2.17.7.2
Changing the Current Site
Procedure:
Perform one of the following actions:
• Press and hold down the preprogrammed Site Search button.
• Press and hold down the Menu Select button directly below RSSI.
When the radio finds a new site, it returns to the Home screen.
2.17.8
Trunked Announcement
The announcement capability allows you to make announcements to the entire user group, as well as
monitor talkgroup calls and other announcements.
Announcement calls are handled in two different ways, depending on the trunked central controller
configuration. The two types are called ruthless and non-ruthless preemption.
6875946M01-JK
Advanced Features
102

Motorola APX 5500 Specifications

General

Number of Channels	Up to 1000 channels
Water Resistance	Yes
IP Rating	IP67
GPS	Yes
Bluetooth	Yes
Wi-Fi	Yes
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Weight	500g (with battery)
Digital Protocol	P25 Phase 1 and Phase 2
Encryption	DES
Display	Color display
