The time interval can be modified by a qualified radio technician.
2.24.15.5
Turning Off Non-Rearmable External Alarms
Procedure:
1 Perform one of the following actions:
• Press the Menu Select button directly below Call, Page or Phon to turn off the external
alarm(s) and access that feature.
• Press the PTT button or any control-head button to turn off the external alarm(s).
The Volume Rocker and the Dim button have no effect on the state of the external alarm(s).
2 Press the Menu Select button directly below H/L momentarily to rearm the horn and lights
feature.
2.24.15.6
Turning Off Rearmable External Alarms
Procedure:
Perform one of the following actions:
• Press the Menu Select button directly below Call, Page or Phon to turn off the external
alarm(s) and access that feature. The external alarm(s) is turned off and automatically
rearmed so that when you exit the entry, the external alarm(s) will automatically turn on.
• Press the PTT button or any control head button other than the Menu Select button directly
below H/L to turn off the external alarm(s). The external alarm(s) is turned off and
automatically rearmed so that when you exit the entry, the external alarm(s) will automatically
turn on.
• Press the Menu Select button directly below H/L to turn off the external alarm(s) and exit the
Horn and Lights feature. Press the Menu Select button directly below H/L momentarily to
rearm the horn and lights feature.
The Volume Rocker and the Dim button have no effect on the state of the external alarm(s).
2.24.16
Front Panel Programming
You are able to customize certain feature parameters in Front Panel Programming (FPP) to enhance
the use of your radio.
2.24.16.1
Entering the Front Panel Programming Mode
You can follow this procedure to enter the front panel programming (FPP) mode on your radio.
2.24.16.1.1
Federal
Procedure:
1 Press
or to FPP and press the Menu Select button directly below FPP.
The radio displays the Enter password screen.
6875946M01-JK
Advanced Features
124

Motorola APX 5500 Specifications

General

Number of Channels	Up to 1000 channels
Water Resistance	Yes
IP Rating	IP67
GPS	Yes
Bluetooth	Yes
Wi-Fi	Yes
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Weight	500g (with battery)
Digital Protocol	P25 Phase 1 and Phase 2
Encryption	DES
Display	Color display
