Motorola APX 5500 User Manual

2.18.4
Required
This option allows the user to power on the radio only if the Ignition is present. The radio can be
powered off either through Power button press or when Ignition is lost. In addition, the radio
automatically powers on when the Ignition is present only if the radio was turned off due to the ignition
being removed.
This option allows the radio to power off when Inactivity Auto Power Off Timer expires, or, when
Ignition Auto Power Off Timer expires.
2.18.5
Soft Power Off
This option allows the user to power on the radio either through Power button presses or when the
Ignition is detected. Meanwhile, if the Power button was pressed or the Ignition was removed, the
radio will be turned off.
This option allows the radio to power off when Inactivity Auto Power Off Timer expires, or, when
Ignition Auto Power Off Timer expires.
2.18.6
Ignition Only Power Up
This option allows the user to power on the radio only when Ignition is detected and will power off when
it is removed. The radio does not power on or off with the Power button press.
This option allows the radio to power off when Inactivity Auto Power Off Timer expires or when Ignition
Auto Power Off Timer expires.
NOTICE:
While Ignition is not present, the radio powers-off with a radio-user Power Off button/knob
selection if the radio was powered-up with an Emergency Power Up footswitch-press or Ignition
Auto Power Off timer is running.
While Ignition is present, the radio powers-on with a radio-user Power On button/knob selection
only if the radio was powered-down with Inactivity Auto Power Off timer.
2.18.7
Using Emergency Power Up
When and where to use: This feature allows the user to power on the radio and automatically
transmits an emergency mode transmission on personalities with emergency enabled, with the use of a
footswitch. In addition, when the Ignition Switch option is set to either Tx Inhibit or PTT Tx Inhibit, this
feature will not be available to the users.
Procedure:
Press the footswitch to turn on the radio and launch Emergency.
A tone sounds and the display shows Emergency.
2.18.8
Auto Power Off Timer
Auto Power Off feature powers off the radio when no user actions occur during a preprogrammed
length of time. There are two different versions of Auto Power Off:
6875946M01-JK
Advanced Features
104
