3 INSTALLATION
19
Data Device Connections
The DCH6416 provides optional high-speed data services such as Internet access,
USB, Ethernet, and more. The functionality of each data device port requires, and
depends on, installed application software.
The DCH6416 rear panel provides the following data ports:
USB 2.0 Can be used to daisy-chain USB devices such as printers and storage devices, or
to interface with keyboards, joysticks, and other USB PC peripherals.
Ethernet 10/100 Mbps RJ-45 port
eSATA Can be used to connect an external hard drive to increase DVR capacity
IEEE-1394 Can be used to connect an MPEG-2 compatible display device
The DCH6416 front panel provides:
USB 2.0 Can be used in the same manner as the rear panel USB 2.0 port
Figure 3-5 Sample data devices you can connect to the DCH6416
