Motorola DCH6416 Installation Manual

4 DIAGNOSTICS
40
Field Description
OSD Front Panel Description
YES on In preview mode
NO off Not in preview mode
MPEG Video
Lock
Indicates whether the video processor is locked to the video stream:
YES—locked
NO—not locked
MPEG Audio
Lock
Indicates whether the audio processor is locked to the audio stream:
YES—locked
NO—not locked
PCR Lock Indicates whether the in-band receiver is locked to the program clock reference
(PCR):
YES—locked
NO—not locked
CCI The copy control information:
00—copy free
01—no more copies
10—copy once
11—never copy
N/A—the value is invalid or cannot be retrieved
APS The Analog Protection System; for example, Macrovision:
00—No Macrovision
11—Type 3 Macrovision
N/A—the value is invalid or cannot be retrieved
RC Flag Displays whether the broadcast flag is present:
0—no flag/not defined
1—the flag is present/enabled
N/A—the value is invalid or cannot be retrieved
CIT The constrained image trigger as delivered in the PRK or the Set DRM API:
1—set
0—not set
N/A—the value is invalid or cannot be retrieved
DRM The digital rights management valid flag bit:
1—set
0—not set
N/A—the value is invalid or cannot be retrieved
RS The retention state:
Forever, 1 week, 2 days, 1 day, 12 hours, 6 hours, 3 hours, 90 minutes, or
Not Defined
N/A—the value is invalid or cannot be retrieved
RF Modem (Upstream)
This diagnostic displays the RF modem status, if an RF modem is installed in the
DCH6416. The information is updated each time this diagnostic is displayed.
