4 DIAGNOSTICS
62
Field Description
I dc INIT_WAIT_DC_O
R_C
The DCH6416 is in the interactive initialization state and
waiting for the default configuration or the contention channel
list messages.
I L WAIT_LM_ACK The DCH6416 is in the interactive initialization state and
waiting for Link Management Response ACK for Local
Address Message.
I SO WAIT_SO_ACK The DCH6416 is in the interactive initialization state and
waiting for a Sign On acknowledgement.
I LA WAIT_LA_OR_SO The DCH6416 is in the interactive initialization state and
waiting for Logical Address or Sign On with verification
Frequency message.
S I INIT_STOPPED The DCH6416 is in the interactive initialization state and the
TransMode has stopped.
r dc RUN_WAIT_DC_
OR_C
The DCH6416 is in the interactive state and waiting for the
default configuration or the contention channel list
messages.
r RUNNING Interactive state is running, sending idle messages, and
waiting for any prepare for poll or MAC messages.
S RUN_STOPPED The interactive run state has stopped and DCH6416 is
waiting for status or a transmission control message.
00 INVALID The interactive state is unknown or invalid.
MAC Abort
Cntr
This counter increments every time the MAC layer reaches the cell abort count limit. It is
reset by the successful upstream transmission of a cell: for example, when the DCH6416
receives an ACK. If the counter reaches the MAC abort count limit, the DCH6416 assumes
the MAC layer is unavailable due to noise, congestion, or some other problem. The
DCH6416 stops transmitting data upstream, reports an error to the calling function, and
attempts to re-enter the network using the initialization process. 0000 is displayed as the
default or if the MAC Abort CNTR is not configured or unknown.
Socket Port
State
The socket mode and activity:
• UNUSED—The socket is not being used.
• OPENED—The socket is open.
• READY—The socket is ready to send or receive.
• RECEIVING—The socket is receiving data from the application server.
• SENDING—The socket is sending data to the application server.
• UNKNOWN—The socket state is invalid or unknown.
