Getting Started 1 - 5
3. Insert the mini-SIM card, as shown in Figure 1-6, with the cut edge of the card facing out and the contacts
facing down.
Figure 1-6
Inserting the mini-SIM Card
4. Lower the mini-SIM card holder and slide it to the left to lock.
5. Install the battery. See Installing the Battery on page 1-5 for more information.
6. After completing initial MC45 setup or after replacing a mini-SIM card:
a. Press the red Power button.
b. Ensure Phone is on.
c. Make a call to verify cellular connection.
Installing the Battery
To install the battery:
1. Insert the battery, bottom first, into the battery compartment in the back of the MC45.
2. Press the battery down into the battery compartment.
NOTE For detailed information about WWAN activation and settings, refer to the MC45 Integrator Guide.
NOTE When installing the battery for the first time out of the box, the back cover and battery are not installed.
NOTE Position the battery correctly, with the battery gold charging contacts positioned on top of the gold charging
pins in the MC45 battery compartment.
