2 - 20 MC45 User Guide
Function Buttons
The MC45’s buttons perform certain functions.
Figure 2-17
Function Buttons
•
Power: Press the red Power button to turn the MC45 screen on and off. The MC45 is in suspend mode when
the screen is off. For more information, see Powering On the MC45 on page 1-8. Also use the Power button
to reset the MC45 by performing a warm or cold boot. See Resetting the MC45 on page 2-17.
•
Scan: Press to scan bar codes or capture images. See Chapter 3, Data Capture.
Or, press to open an application or perform a function. See the Microsoft
®
Applications for Windows
Embedded Handheld 6.5 User Guide to set an application to open.
•
Up/Down: Press to increase or decrease the MC45’s volume.
Volume Buttons
Programmable
Button (Camera)
Power Button
Programmable
Button (Scan)
Up/Down Button
Scan Button
