5 - 4 MC45 User Guide
Fusion Setup
To setup WLAN using Fusion refer to the Wireless Fusion Enterprise Mobility Suite User Guide for Version
H3.40 for detailed information on using and configuring Fusion.
To setup WLAN using Fusion:
1. Tap the Start > > Wireless Configuration Editor > Manage Profiles. The Manage Profiles window
appears.
2. Tap and hold in the window and select Add from the pop-up menu. The Wireless LAN Profile Entry
window appears.
3. In the Profile Name text box enter a name for the profile.
4. In the ESSID text box enter the ESSID.
Figure 5-2
Profile ID Dialog Box
5. Tap Next. The Operating Mode dialog box displays.
6. In the Operating Mode drop-down list, select Infrastructure or Ad-hoc.
Figure 5-3
Operating Mode Dialog Box
7. Tap Next. The Security Mode dialog box displays.
8. In the Security Mode drop-down list, select Legacy (Pre-WPA).
NOTE Obtain the proper WLAN configuration information from your system administrator prior to performing the
Fusion setup procedures.
The following setup procedure example shows setup of a WLAN using WEP encryption.
