Introduction
42 MTS Landmark™ Tabletop Load Units - Product Information
Series 661 Force Transducers
The force transducer commonly used with the axial tabletop Series 370 Load Unit is a Series 661
Force Transducer. There is no manual for the force transducer. The following table provides the
specifications for the force transducers.
Parameter Specification
Capacity
Model 661.19H-03
Model 661.19H-04
Static overload capacity 150% of rating.
15 kN
25 kN
Maximum excitation input 20 V DC
Bridge resistance Axial = 350Ω
Hysteresis 0.05% of full scale
Nonlinearity 0.05% of full-scale axial typical
Temperature
Usable range
Compensated range
0.00044% of full scale/°C (0.0008%/°F)
-54°C to 93°C (-65°F to 200°F)
-18°C to 66°C (0°F to 150°F)
Output
Model 661.19H-03
Model 661.19H-04
1.0 mV/V
2.0 mV/V
Model Load Capacity Thread Size
661.19H-03 15 kN (3.3 kip) M12 x 1.25 mm
661.19H-04 25 kN (5.5 kip) M12 x 1.25 mm
