Operation

78 MTS Landmark™ Tabletop Load Units - Product Information

Interlock logic

The interlock logic is as follows:

Item Description

1 Door Interlock

2 Solenoid Contacts

3 Test Controller Program Interlock Input. Open = Interlock.

4 To Low Flow Power Supply

5 To Controller Program Interlock Chain

Interlock Logic
