Backing Up Site Data
DS2000 Hardware Manual Section 5: Maintenance Options and SMDR ◆ 5-1
5
Section 5: Maintenance
Options and SMDR
Backing Up Site Data
Backing Up Site Data
PC Card Data Base Compatibility
Software version 03.**.** databases are not compatible with any prior 02.**.** versions.
Backing Up Site Data with a PC Card
You can use PC Card P/N 85880 to back up and restore your site data. You cannot store data bases on PC
Card with Software P/N 80051-V03.**.**.
To use the PC Card to back up site data (Figure 5-1):
1. Insert the PC Card into the CPU.
2. Be sure the CPU mode switch is set to RUN.
3. Enter the programming mode.
ICM + #*#* + 372000 + HOLD
4. Dial 9906 + HOLD.
You see: START?
To quit program 9906 instead, dial N + HOLD .
5. Dial Y + HOLD.
You see: 9906: DATABASE NAME
6. Enter a name for the database you want to save (up to 10 characters long).
Refer to Figure 5-2 Entering Names on page 5-3 if you need help when entering names.
Skip this step if you want to save data in an address that already has a name assigned.
7. When you are done entering the name, press HOLD.
You see the name and date of the first database stored. If no data bases are stored, you see:
9906: DB00
(empty)
8. The system assigns the name you entered in step 7 to the data base address you select below:
- Press VOL ▲ or VOL ▼ to scroll through the addresses.
There are 16 data base addresses (DB 00 to DB 15).
OR
- Skip this step to select the currently displayed data base.
To Next Page
