122
REFERENCE ADJUSTMENT
Bright Uniformity Adjustment
This feature allows you to equalize the brightness between the center
and the edge.
Before adjustment:
• Select the “ALL WHITE” pattern using the TEST button on the full
function remote control.
Proceed as follows:
1 Press and hold the CTL button then press the ADJUST button to
display the “REF. ADJUST” menu.
• The projector may ask you to enter your passcode.
• See page 59 for the explanation of the PASSCODE.
2 Use the CURSOR or button to highlight the “2/BRIGHT
UNIFORM.” item. Press the ENTER or INPUT “2” button to
display the “BRIGHT UNIFORMITY” adjustment screen.
3 Use the CURSOR buttons to adjust the right, left, top, or bottom
edge.
• Press CURSOR or button to increase or decrease the
brightness on the right and the left side.
Press CURSOR or button to increase or decrease the
brightness on the top and the bottom side.
4 To end this mode, press the END button.
• Whenever the END button is pressed, the menus will sequence
in this order:
“REF. ADJUST” menu→Source screen
• If the “RETURN USER MODE?” menu appears, use the
CURSOR or button to select either “YES” or “NO” and
then press ENTER. This will exit the REF. ADJUST mode.
Items to select
• YES .......... When you try to enter the ADJUST mode the next
time, you will need to re-enter your passcode.
• NO ........... When you try to enter the ADJUST mode the next
time, you will not need to re-enter your passcode.
– REF. ADJUST –
1 / ASTIG
2 / BRIGHT UNIFORM.
3 / WHITE UNIFORM.
4 / RASTER CENTERING
5 / FOCUS BAL.
6 / REF.WHITE BAL
BRIGHT UNIFORMITY
H
V
BR
60%
60%
To Next Page
