Alignment Adjustment
Correct the horizontal and vertical error for the projected image.
NOTE: Select the CROSS-COARSE test pattern using the TEST
button on the full function remote control.
Proceed as follows:
1 Press the ADJUST button to display the “ADJUST” menu.
• The projector may ask you to enter your passcode.
See page 59 for the explanation of the PASSCODE.
2 Use the CURSOR or button to highlight the “3/ALIGN-
MENT” line. Press ENTER to display the “ALIGNMENT”
menu. You can also select the “ALIGNMENT” menu directly by
pressing the INPUT “3” button.
3 Use the CURSOR or button to select the preferred item.
Press ENTER. You can also select the alignment item directly by
pressing an INPUT button.
• The selected adjustment screen will be displayed.
See page 45 and 46 for the explanation of the selected adjust-
ment.
Items to select
• TILT SKEW .......... Adjusts the tilt and the skew
• BOW .................... Adjusts the horizontal and vertical bow
• AMPLITUDE ........ Adjusts the horizontal and vertical ampli-
tude of the projected image
• LINEARITY .......... Adjusts the horizontal and vertical linearity
• KEY-STONE ......... Adjusts the horizontal and vertical keystone
• PIN-CUSHION ..... Adjusts the horizontal and vertical pincushion
• LINEAR-BAL ........ Adjusts the horizontal and vertical linearity
balance
• KEY-BALANCE ..... Adjusts the horizontal and vertical keystone
tilt balance
• PIN-BALANCE ..... Adjusts the horizontal and vertical pincush-
ion bow balance
• LINE DIST............ Adjusts S shaped distortion of vertical and
horizontal lines
• R,G,B POINT........ Adjusts the horizontal and vertical line in
detail using a intersections on the CROSS-
COARSE pattern as a reference point
NOTE: You can also select adjustments directly using buttons on
the full function remote control. If you are in the CONVERGENCE
mode (see page 48), press and hold down the CTL button then
press the G button. This will bring you to the ALIGNMENT
adjustment screen. To select the “LINEAR-BAL”, “KEY-BALANCE”,
or “PIN-BALANCE”, or “LINE DIST”. alignment, press and hold
down the CTL button then press the LINEAR,KEYSTN, PINCUS, or
BOW button respectively.
– ADJUST –
1 / SIGNAL ENTRY
2 / FOCUS
3 / ALIGNMENT
4 / CONVERGENCE
5 / KELVIN
6 / R,G,B GAIN
7 / PASSCODE
8 / OPTION
9 / REF.ADJUST
– ALIGNMENT –
01 / TILT,SKEW
02 / BOW
03 / AMPLITUDE
04 / LINEARITY
05 / KEY-STONE
06 / PIN-CUSHION
07 / LINEAR-BAL
08 / KEY-BALANCE
09 / PIN-BALANCE
10 / LINE DIST
11 / R,G,B POINT
ADJUSTMENT
