NEC MultiSync XG110LC User Manual

37
ADJUSTMENT
Electrical Focus Adjustment
– ADJUST –
1 / SIGNAL ENTRY
2 / FOCUS
3 / ALIGNMENT
4 / CONVERGENCE
5 / KELVIN
6 / R,G,B GAIN
7 / PASSCODE
8 / OPTION
9 / REF.ADJUST
Adjust the focus electrically to obtain the best screen focus.
NOTE:
• The adjustment must be done to each input.
• Select the FOCUS test pattern using the TEST button on the full
function remote control.
Proceed as follows:
1 Press the ADJUST button to display the “ADJUST” menu.
• The projector may ask you to enter your passcode.
See page 59 for the explanation of the PASS CODE.
2 Use the CURSOR or button to highlight the “2/FOCUS”
line. Press ENTER to display the FOCUS menu. You can also
select the FOCUS menu directly by pressing the INPUT “2”
button.
3 Use the CURSOR or button to highlight your preferred
adjustment item. Press ENTER to display the selected adjustment
screen.
• You can also select the adjustment screen directly by pressing
the INPUT “1” through “4” button.
• For edge focus, you can select either “EDGE ALL” or “EDGE
SEPA.” in the FOCUS EDGE mode of the OPTION menu.
(See page 65).
Items to select
• CENTER ......... The focus adjustment for the center of the
screen (each CRT).
• EDGE ALL ...... The focus adjustment for the edge area of the
screen (all CRTs).
• EDGE SEPA. .. The focus adjustment for the edge area of the
screen (each CRT).
• CORNER. ....... The focus adjustment for the corner of the
screen (each CRT).
NOTE:
• The adjustment screen can also be displayed by pressing the
FOCUS button on the full function remote control. The FOCUS
button rotates the adjustment screen in the above order.
– FOCUS –
1 / CENTER
2 / EDGE ALL
3 / EDGE SEPA.
4 / CORNER
