NEC MultiSync XG110LC User Manual

93
Optional Terminal Baud Rate Selection
This feature allows you to set baud rate of the OPTION terminal
from 4800 to 38400 bps.
NOTE:
• The baud rate of the OPTION terminal defaults to 9600 bps at the
factory.
• Make sure that the baud rate of the OPTION terminal matches that
of operating of the connected equipment.
To change the baud rate of the OPTION terminal, proceed as follows:
1 Press the ADJUST button to display the “ADJUST” menu.
• The projector may ask you to enter your passcode.
See page 59 for the explanation of PASSCODE.
2 Use the CURSOR or button to highlight the “8/OPTION”
line. Press ENTER to display the “OPTION” menu. You can also
select the “OPTION” menu directly by pressing the INPUT “8”
button.
3 Use the CURSOR or button to highlight the “1/SETTING
MODE” line. Press ENTER to display the “SETTING MODE”
menu. You can also select the “SETTING MODE” menu directly
by pressing the INPUT “1” button.
4 Use the CURSOR or button to select the “OPTION
TERM BAUD RATE” item on Page 3, then press ENTER to
display the “OPTION TERM BAUD RATE” menu.
NOTE: The SETTING MODE has three menus. The “OPTION
TERM BAUD RATE” item is on the third menu (P03). To access
P03 from P01, press and hold down the CTL button then press
the button twice; to return to P01 from P03, press and hold
down the CTL button then press the button twice.
5 Use the CURSOR or button to select the baud rate from
4800 to 38400 bps and press ENTER.
6 To end this mode, press the END button.
• Whenever the END button is pressed, the menu will sequence
in this order.
“OPTION” menu→”ADJUST” menu→Source screen.
• IF the “RETURN USER MODE?” menu appears, use the
CURSOR or button to select either “YES” or “NO” and
then press ENTER. This will exit the ADJUST mode.
RETURN USER MODE?
YES NO
– ADJUST –
1 / SIGNAL ENTRY
2 / FOCUS
3 / ALIGNMENT
4 / CONVERGENCE
5 / KELVIN
6 / R,G,B GAIN
7 / PASSCODE
8 / OPTION
9 / REF.ADJUST
– OPTION –
1 / SETTING MODE
2 / MENU MODE
3 / SEQUENCER
4 / PJ ADDRESS
5 / VERSION
6 / HOUR METER
7 / DEFAULT DATA
Items to select
•YES...... When you try to enter the ADJUST mode the next time,
you will need to re-enter your passcode.
•NO ....... When you try to enter the ADJUST mode the next time,
you will not need to re-enter your passcode.
P03/P03
OPTION – SETTING MODE –

DISABLE
OFF
9600 BPS
DIRECT ENTRY ACCESS
B-FOCUS TRACKING
OPTION TERM BAUD RATE

4800
9600
19200
38400
OPTION TERM.
BAUD RATE
SETTING
