NEC MultiSync XG110LC User Manual

57
ADJUSTMENT
Adjusts the color temperature and the white balance.
NOTE:
• When you are in this adjustment mode, all the CRTs will be in use.
The white balance adjustment should be performed for each CRT
(R, G, and B) separately. The CRT beam cannot be cut-off.
• Select the WHITE-WINDOW pattern using the TEST button on the
full function remote control.
Proceed as follows:
1 Press the ADJUST button to display the “ADJUST” menu.
• The projector may ask you to enter your passcode.
See page 59 for the explanation of the PASSCODE.
2 Use the CURSOR or button to highlight the “5/KELVIN”
line. Press ENTER to switch to the “KELVIN.” menu. You can
also select the “KELVIN.” menu directly by pressing the INPUT
“5” button.
3 Use the CURSOR or button to select “COLOR TEMP.” or
“WHITE BAL.” menu.
• The “COLOR TEMPERATURE” and “WHITE BALANCE”
adjustment screen can be also displayed by using the KELVIN
button on the full function remote control.
Color Temperature and White Balance Adjustment
Hold down the CTL button then select the CRT you wish to
adjust with the R, G and B buttons.
Use the CURSOR buttons to adjust the white and the black level.
• The CURSOR button increases the white level.
The CURSOR button decreases the white level.
The CURSOR button increases the black level.
The CURSOR button decreases the black level.
4 Repeat the above steps for the other CRTs if necessary.
5 To end this adjustment, press the END button.
• Whenever the END button is pressed, the menus will sequence
in this order.
“ADJUST” menu → Source screen
• If the “RETURN USER MODE?” menu appears, use the
CURSOR or button to select either “YES” or “NO” and
then press ENTER. This will exit the ADJUST mode.
Items to select
• YES ......... When you try to enter the ADJUST mode again,
you will need to re-enter your passcode.
• NO ........... When you try to enter the ADJUST mode again,
you will not need to re-enter your passcode.
m When selecting “WHITE BAL”
Press ENTER to display the WHITE BALANCE screen.
m When selecting “COLOR TEMP”
Press ENTER to display the COLOR TEMPERATURE screen.
Pressing or increases the color temperature.
Pressing or decreases the color temperature.
• The color temperature ranges from 3200 to 9500k.
RETURN USER MODE?
YES NO
WHITE BALANCE

CRT - R -
60%WHT
10%BLK
COLOR
3200K 9500K
TEMPERATURE
– KELVIN –
1 / COLOR TEMP.
2 / WHITE BAL.

– ADJUST –
1 / SIGNAL ENTRY
2 / FOCUS
3 / ALIGNMENT
4 / CONVERGENCE
5 / KELVIN
6 / R,G,B GAIN
7 / PASSCODE
8 / OPTION
9 / REF.ADJUST
