Manage Device Security
289
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
6. Select the check box for the IP ACL.
7. Click the Delete button.
The IP ACL is removed.
Configure Rules for a Basic IP ACL
Use the IP Rules page to define rules for IP-based standard ACLs (basic ACLs). The access
list definition includes rules that specify whether traffic matching the criteria is forwarded
normally or discarded.
Note: An implicit deny all rule is included at the end of an ACL list. This
means that if an ACL is applied to a packet, and if none of the explicit
rules match, then the final implicit deny all rule applies and the packet
is dropped.
Add a Rule for a Basic IP ACL
 To add a rule for a basic IP ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Security > ACL > Advanced > IP Rules.
