Configure System Information
34
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
The following table describes the USB Memory Statistics information.
The following table describes the USB Directory Details information.
IP Configuration
Use the IP Configuration page to configure network information for the management
interface, which is the logical interface used for in-band connectivity with the switch through
any of the switch’s front-panel ports. The configuration parameters associated with the
switch’s network interface do not affect the configuration of the front panel ports through
which traffic is switched or routed.
 To configure the network information for the management interface:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
Table 4. USB Memory Statistics information
Field Description
Total Size The USB flash device storage size in bytes.
Bytes Used The size of memory used on the USB flash device.
Bytes Free The size of memory free on the USB flash device.
Table 5. USB Directory Details information
Field Description
File Name The name of the file stored in the USB flash drive.
Type The type of file, which can be one of the following:
• Folder. A subfolder within the file.
Click the folder name to view the contents of the subfolder.
• File. A file.
• Other. A path, which can be one of the following:
- Current path. The full path for the folder that is being displayed.
- Parent folder path. The path for the parent folder of the folder
that is being displayed. You can click the entry and open the
parent folder.
File Size The size, in bytes, of the file stored in the USB flash drive.
Modification Time The last modification time of the file stored in the USB flash drive.
