Maintenance
347
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
Send an IPv4 Traceroute
Use this page to tell the switch to send a traceroute request to a specified IP address or host
name. You can use this to discover the paths that packets take to a remote destination. Once
you click the Apply button, the switch sends a traceroute and the results are displayed below
the configurable data.
 To send an IPv4 traceroute:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Maintenance > Troubleshooting > Traceroute IPv4.
6. In the IP Address/Hostname field, enter the IP address or host name of the device for
which the path must be discovered.
The maximum number of characters in a name is 160.
7. In the Probes Per Hop field, enter the number of probes per hop.
The range is 1 to 10. The default value is 3.
8. In the Max TTL field, enter the maximum time to live (TTL) for the destination.
