7-MAINTENANCE

Alternatorandairconditioningcompressor(ifequipped)belt

tension

NOTE:Thealternatorbeltandair-conditioningbelttensioncheckandadjustprocedureonlyapplestomodelsL213,

L215,L218,andL220.

Checkthealternatorbelttensionaftertherst10hofoperationonanewmachineorifanewbelthasbeeninstalled.

Aftertheinitial10h,checkthebelttensionevery10hofoperation.

Alternatorbelttensioncheckandadjust

Usethefollowingproceduretoadjustthealternatorbelt

tension.

1.Loosentheadjustingbracketbolt(2).

2.Pullthealternatortowardtheoutsideofthema-

chinetotightenthebelt.Thebeltistightenedprop-

erlywhenaforceof1kg(2lb)isappliedperpen-

diculartothebeltatthecenterofthespanwitha

3mm(0.118in)deection.

3.Tightentheadjustingbracketbolt(2).

931093161

Airconditioningbelttensioncheckandadjust

Ifyourmachineisequippedwithairconditioning,use

thefollowingproceduretoadjusttheairconditioning

belttension.

1.Loosentheadjustingbracketbolt(1).

2.Pulltheaircompressor(2)towardtheoutsideof

themachinetotightenthebelt.Thebeltistight-

enedproperlywhenaforceof1kg(2lb)isapplied

perpendiculartothebeltatthecenterofthespan

witha3mm(0.118in)deection.

3.Tightentheadjustingbracketbolt(1).

931093162

NOTE:ModelsL223,L225,L230,C227,C232,andC238equippedwithanauthorizedCNHbelttheproperadjust-

mentiswiththealternatorinitsfullyextendedmountingposition.Thesamemachinesequippedwithair-conditioning

(AC)theACcompressormustalsobeinthefullyextendedmountingposition.

7-29
