3-CONTROLSANDINSTRUMENTS
Hcontrolpatternliftarmandbucketcontrols
Liftarmraise/lowercontrol
9310075241
Liftarmraiseandlowercontrol.
•
Theleft-handcontrollever(1)controlstheliftarm.The
liftarmwillraisebypivotingthehandle“UP”totheout-
sideofthecab.Pivotingthehandle“DOWN”tothein-
sideofthecabwilllowertheliftarm.
•
Theliftarmspoolisequippedwithadetent“FLOAT”cir-
cuitiftheoperatorwantstheliftarmtooatoverchang-
inggroundcontour.
FortheElectro-Hydraulic(EH)system,theoatisen-
gagedbypressingtheoatbuttonontheright-hand
controllever(2)andpushingtheleft-handcontrollever
(1)partiallytothedownstroke.Iftheoperatorhasthe
left-handcontrolleverpartiallyinthedownstrokepo-
sitionandthenpressestheoatbutton,theoatwill
engage.Todisengagetheoat,pulltheleft-handcon-
trollevertotheupstrokeslightly.
BS06H186B2
3-17
