7-MAINTENANCE

EVERY250HOURS

Fuellter

Checkthefuellterforwaterevery250hofoperation.

Poorfuelqualitywillrequireyoutodrainthewaterseparatormorefrequentlythan250h.

1.Parkthemachineonlevelground.

2.Turnofftheengine.

3.Opentheenginehood.

4.Opentherearservicedoorandengagethedoorlatch

onthelowerright-handside.

5.Placeacleansuitablecontainerunderneaththefuel

lter.

6.Turnthedrainvalve(1)onthebottomofthefuellter

counter-clockwise2or3turnsanddrainthewateruntil

onlyfuelispresent.Closethevalve.

NOTE:Ifexcesswaterisfoundinthelter,checkthefuel

tank.ContactyourNEWHOLLANDCONSTRUCTIONfor

assistance.

931068631

7-47
