New Holland 200 Series User Manual

7-MAINTENANCE
Drivechaintensioncheck
WARNING
Jackstandscansliporfallover.Dropping,tipping,orslippingofmachineoritscomponentsispos-
sible.
DONOTworkunderavehiclesupportedbyjackstandsonly.Parkmachineonalevelsurface.Block
wheels.Supportmachinewithsafetystands.
Failuretocomplycouldresultindeathorseriousinjury.
W0069A
Checkthetensionofthefourdrivechainsevery250hsofoperation.
1.Withsuitableequipmentproperlysupportthemachine
securelyoffthegroundatthepointsshown(onlyone
sideshown,totalfourlocations).
9310022801
2.Withthemachineofftheground,rotateeachtireand
checkforallowablemovement.6–12mm(0.2–
0.5in)istheacceptablerange.
631074892
Drivechainadjustment
1.Adjusteachaxledrivechainbylooseningtheretaining
nuts(1)(leftfrontshown)andslidingtheaxle-hubas-
semblytoremovetheexcessiveslack.
2.T otightenthechains,slidethefrontaxle-hubsforward
andrearaxle-hubsrearward.
3.T orquetheaxleretaininghardwareto244N·m(180lb
ft).
931093173
7-52

New Holland 200 Series Specifications

General

Brand	New Holland
Model	200 Series
Category	Compact Loader
Language	English
