3-CONTROLSANDINSTRUMENTS
Turningthemachine
Pivotturn-powertoonlyoneside
•
Tomakeapivotturnleft:fromneutral,pushtheleft-
handcontrolleverslightlyforward,andthenlefttothe
10:00position.
•
Tomakeapivotturnright:fromneutral,pushtheleft-
handcontrolleverslightlyforward,andthenrighttothe
2:00position.
•
Tomakeapivotturnreverseleft:fromneutral,pullthe
left-handcontrolleverslightlyrearward,andthenright
tothe4:00position.
•
Tomakeapivotturnreverseright:fromneutral,pullthe
left-handcontrolleverslightlyrearward,andthenleftto
the8:00position.
BS06G0351
Counterrotationturn-powertobothsidesinopposing
directions
•
Tocounter-rotateleft:fromneutral,pushtheleft-hand
controlleverstraighttotheleft(outward)towardthe
9:00position.Theleft-handsidedrivewillengagein
reversetravelastheright-handsidedrivewillengage
forwardtravel.
•
Tocounter-rotateright:fromneutral,pushtheleft-hand
controlleverstraighttotheright(inward)towardthe
3:00position.Theright-handsidedrivewillengagein
reversetravelastheleft-handsidedrivewillengagein
forwardtravel.
BS06G0362
