3-CONTROLSANDINSTRUMENTS

Highowauxiliaryhydraulics

Thehighowauxiliaryhydraulicfeatureprovides207bar(3000psi)orlimitedto132l/min(35USgpm)totheaux-

iliarycircuit.Followtheattachment’soperator’smanualonspecicinstallationprocedures,operation,andremoval

procedures.

Ifthemachineisequippedwithahighowauxiliaryhy-

draulicstherewillbetwo5/8inchcouplers(1)attachedto

thetopofthestandardauxiliaryhydrauliccouplerblock

(2)ontheleft-handloaderarm.

NOTICE:Alwaysusethe5/8inchcouplersduringhigh

owoperationtopreventhighbackpressureandover-

heatingofthehydraulicsystem.

93106839B1

Usethethreepositionswitchontheleft-handROPSpost

toactivatethehighowoption

•

Position(1)—HFHighFlowisactivated

•

Position(2)—Neutralorstandardow

•

Position(3)—HPHighPressureisactivatedif

equippedwithEnhancedHighFlowauxiliaryhydraulics

NOTE:OnlymachinesequippedwithEnhancedhigh

owauxiliaryhydraulicswillbeabletoactivatetheHP

function.

NOTICE:Thehighowswitchmustbeturnedtotheneu-

tralpositionwhennotinuseorrequired.Otherwise,over-

heatingofthehydraulicoilorpoorattachmentoperation

mayoccur.

UsetheProportionalAuxiliary“rotary”switchontheright-

handcontrollevertooperatetheattachmentconnected

tothehighowauxiliaryports.Refertoyourcontrollever

switchcongurations3-23formoredetails.

RCPH11SSL003AAD2

3-31
