ENGLISH – 3
– The manufacturer declines all liability for damages to
property, objects or people resulting from failure to ob-
serve the assembly instructions. In such cases, the war-
ranty for material defects shall not apply.
– The weighted sound pressure level of the emission A is
lower than 70 dB(A).
– Cleaning and maintenance reserved for the user must not
be carried out by unsupervised children.
– Before intervening on the system (maintenance, cleaning),
always disconnect the product from the mains power
supply and from any batteries.
– Inspect the system frequently, in particular the cables,
springs and supports to detect any imbalances and signs
of wear or damage. Do not use the product if it needs to
be repaired or adjusted, because defective installation or
incorrect balancing of the automation can lead to injuries.
– The packing materials of the product must be disposed of
in compliance with local regulations.
– Keep persons away from the gate when it is manoeuvred
using the control elements.
– When operating the gate, keep an eye on the automated
mechanism and keep all bystanders at a safe distance
until the movement has been completed.
– Do not operate the product if anyone is working nearby;
disconnect its power supply before permitting such work
to be done.
1.2 INSTALLATION WARNINGS
– Prior to installing the drive motor, check that all mechan-
ical components are in good working order and properly
balanced, and that the automation can be manoeuvred
correctly.
– Make sure that the control elements are kept far from
moving parts but nonetheless directly within sight. Unless
a selector is used, the control elements must be installed
at least 1.5 m above the ground and must not be acces-
sible.
– If the opening movement is controlled by a re-sensing
system, make sure that any windows larger than 200 mm
are closed using the control elements.
– Prevent and avoid any form of entrapment between the
moving and xed parts during the manoeuvres.
– Permanently afx the label concerning the manual ma-
noeuvre near its actuating element.
– After installing the drive motor, make sure that the mecha-
nism, protective system and all manual manoeuvres func-
tion properly.
PRODUCT DESCRIPTION AND
INTENDED USE
2
2 PRODUCT DESCRIPTION AND INTENDED USE
WIDE are electromechanical road barrier mechanisms for residen-
tial, public and industrial use, which control the opening and clos-
ing of a driveway.
These barriers are equipped with an electromechanical gearmotor
with a 24 V motor.
The control unit is congured for connection to devices belonging
to the Opera System Nice.
The barriers work on electricity and in case of a power outage
(blackout), the boom can be unlocked manually and moved by
hand. Alternatively, it is possible to use the back-up battery (model
PS324 - optional accessory) which ensures that certain manoeu-
vres can be carried out in the rst few hours of a power outage.
The barriers must be combined with the available booms, individ-
ually or in pairs, to reach the desired length. Various optional ac-
cessories are available, depending on the chosen boom, as shown
in the table.
Table 1
INSTALLABLE ACCESSORIES
Cubicle WIDE S WIDE M WIDE L
Boom 3 m 4 m 4 m 5 m 3+3 m 3+4 m
Rubber yes yes yes yes yes yes
Lights yes yes yes yes yes yes
Pivoting
attachment
yes yes yes - - -
Jointed boom - - yes - - -
Aluminium
skirt
1 pcs - 2 pcs 2 pcs 2 pcs -
Mobile support - - 1 pcs 1 pcs 1 pcs -
Important notes for using the manual:
– throughout this manual, the term "boom gate" refers to the three
products "WIDE S", "WIDE M" and "WIDE L"
– the accessories mentioned in the manual are optional.
a
Any use of the product other than the intended use
described is not allowed!
