34 – ENGLISH
TECHNICAL SPECIFICATIONS
12
13 TECHNICAL SPECIFICATIONS
l
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). Nice S.p.A.
reserves the right to apply modications to the product at any time when deemed necessary, without altering
its functions and intended use.
Table 13
TECHNICAL SPECIFICATIONS
Description Technical specication
WIDES - WIDESI WIDEM - WIDEMI - WIDEMS WIDEL - WIDELI - WIDELS
Product type Boom gate for residential use inclusive of electronic control unit
Power supply
220-230VC 50/60Hz
Maximum power consumption (W) 300 300 360
Maximum current draw (A) 1 1,1 1,2
Current draw in stand-by
8 mA - 24 Vc
Minimum opening time (sec) 4 3,5 5
Rated torque (Nm) 100 140 200
Maximum frequency of operating
cycles/hour (at nominal torque)
100 300 200
Services power output
24 Vc maximum current 200 mA (the voltage may vary between 16 V and 33 Vc)
Emergency power supply With optional accessory PS324
Photo test output
24 Vc maximum current 100 mA (the voltage may vary between 16 V and 33 Vc), connect Nice
photocells exclusively
Flash output for 1 ML24 or ML24T ashing light (maximum lamp power = 25 W)
Courtesy light output 24V lamp output (max 10 W)
OGI output for 24 V (max 10 W) indicator light
Alt input Conguration of "ALT" input (NC, NO, 8k2, 4k1) with default NC.
Step-By-Step input For normally open contacts
Open input For normally open contacts
Close input For normally open contacts
Radio connector SM connector for SMXI, SMXIS, OXI and OXIT receivers
Radio ANTENNA input 50 Ω for RG58-type cable or similar
Adjustable functions
using the trimmers (see chapter "Adjusting the trimmers") and micro switches (see chapter"
Programming the control unit")
Use in highly acid, saline or potentially
explosive atmosphere
No
Operating temperature -20°C ÷ 55°C
Protection rating IP54
Dimensions and weight 280x178x1000h mm; 40 kg 320x205x1000h mm; 46 kg 420x205x1030h mm; 54 kg
