60 - FORM NO. 56043088 / Advenger
™
/ BR 600S, 650S, 700S, 800S
ELECTRICAL SYSTEM
MAIN CONTROL BOARD SPECIAL PROGRAM OPTIONS
Displaying the Control Unit Revision Level:
If it is desired to view the revision level of the control unit perform the following steps:
1 Turn the main power key switch to the off position.
2 Press and hold the scrub system off switch and the speed select switch.
3 While holding both switches turn the main power key switch to the on position.
4 Continue to hold both switches until the speed select indicator is fl ashing.
5 Release both switches.
6 The status display will now indicate the revision level of the control unit. The displayed value will be a letter from A to Z.
7 To exit this mode, turn the main power key switch to the off position.
Selection of Low Voltage Cutout Threshold:
FACTORY DEFAULT: S (STANDARD)
The Advenger is equipped with a low voltage cutout feature to prevent over-discharging the batteries. This feature will automatically shut down the
scrub system when the battery voltage falls to the selected threshold. The cutout level is adjustable. The standard setting is 31 volts (1.72 volts per
cell) and the alternate setting is 32.5 volts (1.81 volts per cell). Select the proper cutout level based on the battery manufacturer’s specifi cations. It
is important to note that some maintenance free batteries (including some gelled electrolyte cells) are capable of being safely discharged down to
1.72 volts per cell. To select between the two cutout levels:
1 Turn the main power key switch to the off position.
2 Press and hold the scrub system off switch.
3 While holding the scrub system off switch turn the main power key switch to the on position.
4 Continue to hold the scrub system off switch until the scrub off indicator turns green.
5 Release the scrub off switch.
6 The status display will now show “S” or “A”. Pressing and releasing the scrub off switch will now select between the two options. For the standard
cutout level, select “S”. For the alternate cutout level, select “A”.
7 To save the new setting, turn the main power key switch to the off position.
8 The new setting will be saved and will remain in effect until it is changed again.
Selection of Scrub Switch Operation and Scrub Pressure Limits:
FACTORY DEFAULT: MODE = 1 (PRESSURE INCREASE/DECREASE MODE), LIMIT = 9 (MAXIMUM)
The scrub system switches on the Advenger/BR 600, 650, 700 & 800 can be programmed to operate three different ways. The operation of the
scrub mode switches is described in the user manual. Following is a description of how to program the control for each mode of operation:
NOTE: There are three control panel switches associated with the scrub system. The left-most switch is the scrub system off switch. The center
switch is mainly referred to as the scrub pressure decrease switch. Depending on the scrub switch operating mode, this switch may also be referred
to as the light scrub pressure select switch. The right-most switch is mainly referred to as the scrub pressure increase switch. Depending on the
scrub switch operating mode, this switch may also be referred to as the heavy scrub pressure select switch.
Pressure Increase / Decrease Mode (Factory Default)
1 Turn the main power key switch to the off position.
2 Press and hold the scrub pressure decrease switch.
3 While holding the pressure decrease switch turn the main power key switch to the on position.
4 Continue to hold the pressure decrease switch until the scrub pressure decrease indicator is green.
5 Release the pressure decrease switch.
6 Pressing and releasing the scrub pressure decrease switch will now select between “0” for no adjustable pressures (fi xed pressure mode), “1”
for one adjustable pressure (pressure increase/decrease mode) or “2” for two adjustable pressures (light/heavy scrub pressure mode). Set the
mode to “1”.
7 Press the scrub system off switch to save this setting.
8 The status display will now show a number from 1 to 9. This represents the maximum scrub pressure that the operator will be able to select.
Use the pressure decrease switch to set the desired pressure limit.
9 Press the scrub system off switch to save this setting.
10 The status display will now show “d” to indicate that the procedure is done.
11 The new setting will be saved and will remain in effect until it is changed again.
