Appendix
104 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
8
8
.
.
6
6
.
.
4
4
D
D
E
E
T
T
E
E
C
C
T
T
O
O
R
R
S
S
E
E
N
N
S
S
I
I
T
T
I
I
V
V
I
I
T
T
Y
Y
The control panel provides nine Sensitivity Levels for alarm detection and pre-alarm as follows:
• Alarm Sensitivity Levels You can select the sensitivity of a detector from 1 to 9 (1=highest sensitivity; 9=lowest
sensitivity).
• Pre-Alarm Sensitivity Levels You can select one of nine levels from 1 to 9 (0=no Pre-Alarm, 1=self-optimizing,
2=highest sensitivity, 9=lowest sensitivity).
You can set the sensitivity levels as fixed or programmed for day and night operation.
Analog Addressable Detectors Sensitivity Settings Table
Detector Type
Alarm
%/Meter Obscuration
Pre-Alarm
%/Meter Obscuration
Photo Optical
Level 1 1.64% Auto
Level 2 2.40% 0.98%
Level 3 3.15% 1.54%
Level 4 3.90% 2.10%
Level 5 4.69% 2.66%
Level 6 5.45% 3.25%
Level 7 6.20% 3.81%
Default
Level 8 6.96% 4.36%
Level 9 7.71% 4.92%
Ionisation
Level 1 1.64% Auto
Level 2 2.46% 1.31%
Level 3 3.28% 1.64%
Level 4 4.10% 2.46%
Level 5 4.92% 3.28%
Level 6 5.74% 4.10%
Level 7 6.56% 4.92%
Default
Level 8 7.38% 5.74%
Level 9 8.20% 6.56%
View/Laser
Level 1 0.07% Auto
Level 2 0.16% 0.07%
Level 3 0.33% 0.16%
Level 4 0.66% 0.33%
Level 5 0.98% 0.66%
Level 6 1.64% 0.98%
Level 7 2.30% 1.64%
Default
Level 8 3.28% 2.30%
Level 9 6.56% 3.28%
Acclimate
Level 1 1.63% 1.63%
Level 2 3.25% 3.25%
Level 3 3.25 – 6.5% Auto 3.25%
Level 4 6.5 % 3.25 – 6.5% Auto
Level 5 6.5 – 9.75% Auto 3.25 – 6.5% Auto
Level 6 9.75% 6.5%
Level 7 9.75 – 13.0% Auto 6.5%
Default
Level 8 13.0% 6.5 - 9.75% Auto
Level 9 63
O
C degrees Heat Only 6.5 - 9.75% Auto
