Notifier AFP-2800 User Manual

Appendix
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 130
8
8
.
.
1
1
2
2
.
.
2
2
F
F
A
A
N
N
C
C
O
O
N
N
T
T
R
R
O
O
L
L
L
L
E
E
R
R
+IN
-IN
+OUT
-OUT
SHIELD
COMMS CABLE FROM
PREVIOUS MODULE
COMMS CABLE TO
NEXT MODULE
SOCKET
OUTPUT FUNCTION 1
OUTPUT FUNCTION 2
OUTPUT FUNCTION 3
0V From Previous Module
+24V From Previous Module
0V To Next Module
+24V To Next Module
INPUT 1
INPUT 2
INPUT 3
Note: Between Field modules, connect shields together outside of their respective enclosures. Make sure that the shield is only grounded at the FIP and not at the modules or
annunciators.
