Panel Operation
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 71
All points to be tested are automatically isolated during the test.
If a point is in the walk test list, the FIP will treat it as inactive in scripts. The FIP will also bypass AVF for the point.
As the user walks around and activates the inputs, the FIP will mark the point as active and record the event in
history. As each point in the walk test list is activated a user selectable output will turn on for 2 seconds. If any
point which is not in the walk test list goes into alarm, the panel will terminate the walk test and go back to normal
operation. The same applies if no new walk test events have been received for 30 minutes after starting the walk
test.
Once the START button is pressed, you must manually put each point under test into alarm, one by one. They will
all remain in alarm until the test is stopped. As each one goes into alarm, the Walk Test Output Target selected
previously will activate for approximately 2 seconds. At the conclusion of the test, the points list on the display will
indicate each device tested that has passed the alarm test.
6
6
.
.
3
3
.
.
7
7
S
S
E
E
R
R
V
V
I
I
C
C
E
E
M
M
E
E
N
N
U
U
–
–
G
G
L
L
O
O
B
B
A
A
L
L
This menu items provides the ability to set system wide global parameters for various items, site contact details
and also set the systems date and time.
1) SYSTEM ........ SET GLOBAL PARAMETERS
2) TIME .......... SET THE DATE/TIME
3) DAY-NIGHT ..... SET DAY/NIGHT TIMES
4) PASSWORDS ..... SET SYSTEM PASSWORDS
5) SITE .......... SET NAME & CONTACT INFO
GLOBAL CONFIGURATION MENU
SELECTDOWNUP MENU
SELECT A FUNCTION:
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 1
DAY MODE
Actions:
Use the UP and DOWN buttons to scroll
through options and then use the SELECT
button to select the highlighted option
(or button 1 to 5 from the numeric keypad)
Press the MENU button to return to the
Service Menu screen.
