Note: AFP-2802 does not support networking. The rest of this section only applies to the AFP-2800 FIP.
This menu is used to enter the network operating parameters and display network information for the panel.
Networking is only available on panels with V3.xx or higher firmware version.
1) NETWORK VIEW NODES FOUND ON THE NETWORK
2) STATUS DISPLAY REMOTE POINT INFORMATION
3) NODE ENABLE/DISABLE NETWORK – SET NODE NO
4) RECEIVE SET EVENTS ACCEPTED FROM OTHER NODES
5) OPTIONS CONFIGURE NETWORK SETTINGS
NETWORK MENU
SELECTDOWNUP BACK
USE UP/DOWN BUTTONS TO SELECT A FUNCTION
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 1
DAY MODE
SELECTDOWNUP BACK
Actions:
 Use the UP and DOWN buttons to scroll
through options and then use the SELECT
button to select the highlighted option
(or button 1 to 5 from the numeric keypad)
 Press the BACK button to return to the
Service Menu screen.
6.3.9.1 SERVICE MENU – NETWORK – NETWORK
This option will display a list of nodes found on the network. The node list is updated automatically and displays
the active nodes on the network
NODE 1 
NODES FOUND ON RING 4:
001 002 003 100 120 240
NETWORK NODE MENU
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 1
DAY MODE
BACK
Actions:
 Press the BACK button to return to the
Service Menu screen.
6.3.9.2 SERVICE MENU – NETWORK – STATUS
This menu will allow the operator to perform a read status on zones and points programmed on a remote node.
