Appendix
128 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
8.11 FIELD REPLACEMENT PARTS:
The following parts are replaceable on-site.
Sub assemblies are replaceable on site, provided the system is fully powered down. Replacing a PCB with power
connected can permanently damage equipment and void all warranties.
Any malfunctioning circuit boards must be returned to the factory for repair and full retest. There are no user
serviceable parts on-board. Any attempt to repair circuit boards by personal, other than a certified factory
technician, will void all warranties.
Sub Assemblies:
Part # Description
PCB/713 AFP-2800/2802 CPU board
PCB/724 AFP-2800/2802 Main termination board
2800/LIM AFP-2800/2802 Loop Interface Module (Analog addressable)
2800/NIM AFP-2800 Network Interface Module
2800/LCM AFP-2800/2802 Addressable Loop Driver – Master (Loops
1,3,5,7,9)
2800/LEM AFP-2800/2802 Addressable Loop Driver – Slave (Loops
2,4,6,8,10)
2800/16AT AFP-2800/2802 Annunciator – 16AT
2800/32A AFP-2800/2802 Annunciator – 32A
2800/SCS8 AFP-2800/2802 Annunciator – SCS8
2800/PS243 AFP-2800/2802 3 Amp power supply.
2800/PS249 AFP-2800/2802 9 Amp power supply.
2800/NPS-2 AFP-2800/2802 2.6 Amp power supply.
2800/NPS-5 AFP-2800/2802 5.5 Amp power supply.
2800/NPS-11 AFP-2800/2802 11.7 Amp power supply.
Replacement parts:
Part # Description Rating
FUSE-M205-1A TERMINATION BOARD FUSES 1A
