4-3 Recommended Connector Cables
4-28
4-3 Recommended Connector Cables
Always use recommended connectors, connector hoods, and cables, where possible, when
making connector cables. Depending on the Unit, a connector and connector hood may be
included with the Unit.
Check the required components before preparing them.
Name Model Details
Units with the connectors and
connector hoods included.
XM2A-0901
9-pin type
made by OMRON.
CS/CJ Series
C-series CQM1 and C200HS
C200HX/HG/HE(-Z)
CVM1/CV-series CPU Units
CV500-LK201
Connector
XM2A-2501
25-pin type
made by OMRON.
CV500-LK201
C200H-LK201-V1
XM2S-0911
9-pin type
made by OMRON.
(mm screws)
C-series CQM1 and C200HS
C200HX/HG/HE(-Z)
CVM1/CV-series CPU Units
CV500-LK201
XM2S-0911-E
9-pin type
made by OMRON.
CS/CJ Series
XM2S-0913
9-pin type
made by OMRON.
(inch screws)
Connector
Hood
XM2S-2511
25-pin type
made by OMRON.
CV500-LK201
C200H-LK201-V1
AWG28 × 5P
IFVV-SB
Multiconductor shielded cable
made by Fujikura Densen, Ltd.
Cable
CO-MA-VV-SB
5P × 28AWG
Multiconductor shielded cable
made by Hitachi Densen, Ltd.
Note The connector’s tensile load is 30 N max. Do not subject the connectors to a load greater
than that specified.
• OMRON Cables with Connectors
The following OMRON Cables with Connectors can be used.
Model Cable length Connector specifications
XW2Z-200T 2 m
XW2Z-500T 5 m
9-pin-to-9-pin
XW2Z-200T-2 2 m
XW2Z-200T-5 5 m
9-pin-to-CPM2C peripheral port
• OMRON Cables for CS1-series PLC Peripheral Port
Model Cable length Connector specifications
CS1W-CN118 0.1 m 9-pin (female)-to-CS1-series peripheral port
• OMRON RS-232C/RS-422A Converter
Model Connection method Terminal block specifications
NS-AL002
Connects directly to
RS-232C port.
8-pole terminal block (1:N NT Link)
The connectors for the connecting cables are not included with the PT and must be pur-
chased separately.
